15Mo3 Plate Suppliers
15Mo3 Plate Stockist, 15mo3 Alloy Cr Plates Stockholder, 15mo3 Plates Exporter, Din 1.5415 Alloy Steel High Quality Plates Stockist
Astm A204 15mo3 Alloy Steel Chequered Plate Supplier, A204 Alloy Steel 15mo3 Plates Exporter In India, Alloy Steel 15mo3 Plate Distributors, Alloy Steel 15mo3 Cold Rolled Plate Dealer, Alloy Steel Hr Plate, Asme Sa204 15mo3 Plates Exporter, Alloy Steel Hot Rolled Plates Manufacturer & Suppliers
15Mo3 steel plate / sheet, DIN 17155 15Mo3 steel plate / sheet, under DIN 17155 standard, we can supply 15Mo3 steel plate / sheet for boiler steels. 15Mo3 steel plate / sheet is one mainly of Steel for boiler steels.DIN 17155 15Mo3 steel is mainly used for boilers and pressure vessels with elevated temperatures which is equivalent to EN10028 16Mo3 and UNI5869 15Mo3, 15D3 (NFA 36205 ) and ASTM A204Gr.B.
15Mo3 Steel Plate Specifications
| Specifications | ASTM A387 / ASME SA387, ASTM A204 / ASME SA204 |
| Standard | ASTM, ASME and API |
| Thickness | 4.0mm – 100mm |
| Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish |
Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
|
| Hardness |
Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
|
| Grade |
Alloy Steel ASTM A387 Grade 16MO3, 15MO3, ASTM A204 A, ASTM A204 B Plates, ASTM A204 16MO3, ASTM A204 15MO3, Alloy Steel A204 GR.A, (UNS K11820) Plates
|
| Ready stock |
|
Comparision of steel grades
| 15Mo3 DIN 17155 Number:1.5415 | EN 10028-2 | 16 Mo 3 |
| NFA 36-205 | 15 D3 | |
| UNI 5869 | 15 Mo 3 | |
| BS 1501 | 1503 – 243 B | |
| UNE 36087 | 16 Mo 3 | |
| ASTM | A 204 Gr. B | |
| JIS G3115 | – |
DIN 15Mo3 steel Chemical Composition
| 15MO3 | C | Mn | S | N | Cu | Si | P | Cr | Ni | Mo |
| 0.12- 0.2 | 0.40- 0.90 | 0.01 | 0.012 | 0.30 | 0.35 | 0.025 | 0.30 | 0.30 | 0.25- 0.35 |
DIN 15Mo3 steel Mechanical Propertites
| Grade | 15MO3 | ||||
| 15MO3 | Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation in 100-150 mm(%) |
Elongation in 16 mm(%) |
Max Thickness (mm) |
| 440-590 | 220-275 | 19 | 24 | 250 | |
Physical property for 15Mo3 Boiler steel Plate :
| Thickness (mm) | |||||
| 15Mo3 | ≤ 16 | > 16 ≤ 40 | > 40 ≤ 60 | > 60 ≤ 100 | > 100 |
| Yield strength (≥Mpa) | 275 | 270 | 260 | 240 | 220 |
| ≤ 60 | > 60 ≤ 100 | > 100 | |||
| Tensile strength (Mpa) | 440-590 | 430-580 | 420-570 | ||
15MO3 Plates Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN | BS | GOST |
| 15MO3 | 1.5415 | – | JIS G3115 | EN 10028-2 | BS 1501 | – |
Types of Alloy Steel 15MO3 Plates
|
|
Specialized in:
15MO3 Alloy Steel Plates 2B NO.1, 1mm thick Alloy steel plate 15MO3, Manufacturer preferential supply High Quality 15MO3 Alloy Steel 15MO3 Alloy Steel plate Alloy steel shim plate 15MO3, ASTM 15MO3 Alloy steel polished sheet prime quality plate, cold rolled 15MO3 20mm thick Alloy steel plate, Alloy steel plate 3mm thick 15MO3, Alloy AISI 15MO3 Super Mirror Alloy Steel Plate Manufacture, 15MO3 AISI Alloy steel sheet/plate factory, 15MO3 Alloy steel plate hot rolled Plate, Alloy steel diamond checkered plate NO.1 15MO3 AISI 15MO3 Alloy steel plate AISI 15MO3 Alloy steel plate, 15MO3 Alloy steel round plate, High Quality 15MO3 Decorative Alloy Steel Laser Plate, Best Quality Sales for sus 15MO3 Alloy steel plates, 15MO3 8K/mirror color Alloy steel plates for elevator decoration, 15MO3 Alloy Steel Price, aisi 15MO3 Alloy steel plate for construction, 15MO3 NO.1 surface Alloy steel plate, 15MO3 Alloy Steel Sheet Price
Technical Requirements & Additional Services:
- Low temperature impacting test
- Rolling under standard NACE MR-0175 (HIC+SSCC)
- Ultrasonic test under EN 10160,ASTM A435, A577,A578
- Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
- Shot blasting and Painting,Cutting and welding as per end user’s demands
15Mo3 Plate Processing
The majority of normal processing can be performed on 15Mo3 Plate
MD Exports LLP Offers Following process for 15Mo3 Plate
15Mo3 Plate Packing & Shipping
Each order is packaged according to the customer’ s standards including preparation for export such as wooden case, pallet or according to customer’s requirement All shipping documentation is provided for 15Mo3 Plate delivery from mill to customer.
Every assignment begins with a visit of our experienced sales representative who assesses the volume / weight of the belongings and brief the client about the nature of packing required as well as various documentation formalities when moving from India.
Supply Area :
We Supply Our 15Mo3 Plate to various countries like Saudi arabia, Kuwait, Qatar, Oman, Yemen, UAE, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Vietnam, South Africa,South America,Brazil, India, Australia, Egypt.
15Mo3 Plate Inventory
15Mo3 Plate Application Industries
MD Exports LLP offers a broad range of 15Mo3 Plate through a worldwide network of stock-keeping branches.these 15Mo3 Plate is use in various industries like:
- Fertilizers Industry
- Aerospace Industry
- Nuclear Power Plant Industry
- Chemical Industry
- Oil & Gas Industry
- Refineries Industry
- Petrochemical Industry
- Paper Industry
MD Exports LLP inc is largest suppliers of 15Mo3 Plate. we are supplying 15Mo3 Plate in Saudi arabia, Kuwait, Qatar, Oman, Yemen, UAE, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Vietnam, South Africa,South America,Brazil, India, Australia, Egypt.we assured our client that we are standing behind our product which we have supplied as well as we issued a quality certificate along with our product which we manufacture supplies and exports
