Molybdenum Plate Suppliers
Molybdenum Plate Stockist, Molybdenum Sheet Manufacturers, Suppliers & Traders in Mumbai, Molybdenum Strips
Hot Rolled Molybdenum Plate, Hot Rolled Molybdenum Plate, Sintered Molybdenum Sheet Stockist
High purity molybdenum plate possesses unique properties that are suitable for use in a number of applications and industries. MD Exports LLP can cut, size, or roll the products to customer-specified thickness, length, and surface finish, as well as customize other material properties. Molybdenum Plates are very hard, but softer and more ductile than tungsten. These Molybdenum Sheet is used in a diverse array of applications including precision sputtering targets, machining blanks, furnace hearth rails, x-ray shielding, nuclear fuel sintering boats, and others.
Product name: Molybdenum Plate
Standard: ASTM B386
Material: Mo >99.95%
Density: >10.2g/cc
Molybdenum sheet plate Specification :
| Materials | R03600, R03620,R03630, R03650,etc |
| Standard | ASTM B386 |
| Thickness | 0.1-100mm |
| Width | 20-1500mm |
| Technology | Hot-Rolled, Cold-Rolled, Machining |
| Condition | Vacuum Anneal |
| Surface | Mill, Polished, Bright, Sand blast,etc |
We supply high quality molybdenum plate as one of our hot product. Below are most of the standard sizes. Our plate products are normally limited to 80 kilograms maximum weight per piece. If you do not see the size of molybdenum plate that you require, please feel free to contact us.
|
Thickness |
Max. Width |
Max. Length |
Thickness Tolerance |
|---|---|---|---|
|
0.090" ~ 0.200" |
30" |
114" |
+/- 0.008" |
|
0.200" ~ 0.250" |
24" |
84" |
+/- 2% |
|
0.250" ~ 0.500" |
24" |
42" |
+/- 2% |
|
>0.500" |
24" |
+/- 2% |
Molybdenum Plate Surface Condition:
Surface can be supplied in a shiny, matte, satin, or as-rolled condition; dependent upon thickness and width parameters.
Molybdenum Plate Heat treatment:
Molybdenum flat products are rolled and annealed to provide the optimum condition for the desired end use.
Molybdenum Plate Application:
Material from .090 inches to 3 inches in thickness is classified as molybdenum plate. It is widely used in the construction of furnace tooling and parts and as a feed stock for the fabrication of parts for the electronics and semiconductor industries.
Molybdenum Plate Composition:
|
Brand |
Mo-1 |
Mo-2 |
Mo-3 |
|
|---|---|---|---|---|
|
Mo(%) |
99.95 |
99.95 |
99.95 |
|
|
Other Element Content(%) ≤ |
Pb |
— |
— |
0.001 |
|
Bi |
— |
— |
0.001 |
|
|
Sn |
— |
— |
0.001 |
|
|
Sd |
— |
— |
0.001 |
|
|
Cd |
— |
— |
0.001 |
|
|
Fe |
0.005 |
0.006 |
0.010 |
|
|
Ni |
0.002 |
0.003 |
0.005 |
|
|
Al |
0.002 |
0.002 |
0.005 |
|
|
Si |
0.003 |
0.003 |
0.010 |
|
|
Ca |
0.002 |
0.002 |
0.005 |
|
|
Mg |
0.001 |
0.002 |
0.003 |
|
|
P |
0.001 |
0.001 |
0.002 |
|
|
C |
0.005 |
0.008 |
0.010 |
|
|
O |
0.003 |
0.005 |
0.050 |
|
|
N |
0.001 |
0.003 |
– |
|
|
Use for example |
Precision Manufacture |
Standard Manufacture |
Alloy Addition |
|
Molybdenum Sheet, Plate & Foil Sizes
| Material | Format | Size Inches “ | Size MM |
|---|---|---|---|
| Molybdenum | Foil | 0.001 | 0.025 |
| Molybdenum | Foil | 0.002 | 0.050 |
| Molybdenum | Foil | 0.003 | 0.080 |
| Molybdenum | Foil | 0.004 | 0.100 |
| Molybdenum | Foil | 0.005 | 0.127 |
| Molybdenum | Foil / Sheet | 0.006 | 0.150 |
| Molybdenum | Foil / Sheet | 0.007 | 0.178 |
| Molybdenum | Foil / Sheet | 0.008 | 0.200 |
| Molybdenum | Foil / Sheet | 0.010 | 0.250 |
| Molybdenum | Sheet | 0.015 | 0.381 |
| Molybdenum | Sheet | 0.020 | 0.500 |
| Molybdenum | Sheet | 0.025 | 0.635 |
| Molybdenum | Sheet | 0.030 | 0.762 |
| Molybdenum | Sheet | 0.039 | 1.000 |
| Molybdenum | Sheet | 0.040 | 1.016 |
| Molybdenum | Sheet | 0.050 | 1.270 |
| Molybdenum | Sheet | 0.059 | 1.500 |
| Molybdenum | Sheet | 0.060 | 1.524 |
| Molybdenum | Sheet | 0.079 | 2.000 |
| Molybdenum | Sheet | 0.080 | 2.032 |
| Molybdenum | Sheet | 0.090 | 2.286 |
| Molybdenum | Sheet | 0.098 | 2.500 |
| Molybdenum | Sheet | 0.100 | 2.540 |
| Molybdenum | Sheet | 0.118 | 3.000 |
| Molybdenum | Sheet | 0.125 | 3.175 |
| Molybdenum | Sheet | 0.150 | 3.810 |
| Molybdenum | Sheet | 0.157 | 4.000 |
| Molybdenum | Sheet / Plate | 0.187 | 4.763 |
| Molybdenum | Plate | 0.197 | 5.000 |
| Molybdenum | Plate | 0.200 | 5.080 |
| Molybdenum | Plate | 0.250 | 6.350 |
| Molybdenum | Plate | 0.270 | 6.858 |
| Molybdenum | Plate | 0.300 | 7.620 |
| Molybdenum | Plate | 0.313 | 7.938 |
| Molybdenum | Plate | 0.375 | 9.525 |
| Molybdenum | Plate | 0.394 | 10.000 |
| Molybdenum | Plate | 0.410 | 10.414 |
| Molybdenum | Plate | 0.500 | 12.700 |
| Molybdenum | Plate | 0.591 | 15.000 |
| Molybdenum | Plate | 0.625 | 15.875 |
| Molybdenum | Plate | 0.750 | 19.050 |
| Molybdenum | Plate | 0.787 | 20.000 |
| Molybdenum | Plate | 1.000 | 25.400 |
| Molybdenum | Plate | 1.125 | 28.575 |
| Molybdenum | Plate | 1.187 | 30.150 |
| Molybdenum | Plate | 1.250 | 31.750 |
| Molybdenum | Plate | 1.375 | 34.925 |
| Molybdenum | Plate | 1.500 | 38.100 |
| Molybdenum | Plate | 1.750 | 44.450 |
| Molybdenum | Plate | 2.000 | 50.800 |
| Molybdenum | Plate | 2.500 | 63.500 |
| Molybdenum | Plate | 3.000 | 76.201 |
| Molybdenum Sheet Stockist in India | ||
|---|---|---|
| .003" x 12" x 36" | .020" x 12" x 36" | .060" x 12" x 36" |
| .005" x 12" x 36" | .025" x 12" x 36" | .070" x 12" x 36" |
| .010" x 12" x 36" | .030" x 12" x 36" | .090" x 12" x 36" |
| .012" x 12" x 36" | .040" x 12" x 36" | .100" x 12" x 36" |
| .015" x 12" x 36" | .050" x 12" x 36" | .125" x 12" x 36" |
| Molybdenum Plate Stock in Mumbai | ||
| .187" x 12" x 36" | .500" x 12" x 36" | 1" x 12" x 36" |
| .250" x 12" x 36" | .625" x 12" x 36" | 1.25" x 12" x 36" |
| .375" x 12" x 36" | .750" x 12" x 36" | |
| Molybdenum Forms and Tolerances | |||
|---|---|---|---|
| Form | Thickness | Width | Length |
| Sheet | 0.005” to 0.187” | 24” max. | sheet ** |
| (0.127 to 4.750 mm) | (610 mm) | (2.438 m) or coil* | |
| Foil | 0.001” to 0.0049” | 1/2” to 12” | coil |
| (0.0254 to 0.12 mm) | ( 12.7 to 305 mm) | ||
Molybdenum Pure Products
PD-7000 Pure Molybdenum AC Bar Low Carbon
PD-7006 Pure Molybdenum AC Bar
PD-7009 Pure Molybdenum PB PM Bar
PD-7010 Pure Molybdenum PSB PM Billet
PD-7029 Pure Molybdenum Plate PP-22-2
PD-7014 Pure Molybdenum Sheet Premium Grade PS-100-2
PD-7016 Pure Molybdenum Sheet Standard Grade PS-300-2
PD-7017 Pure Molybdenum Foil F-21-5
PD-7026 Pure Molybdenum ABL AC Bar Low Carbon
PD-7028 Pure Molybdenum ASL AC Sheet 3202 Low Carbon
PD-7030 Pure Molybdenum APL AC Plate 3203 Low Carbon
Molybdenum Alloys Products
PD-7001 Molybdenum Alloy TZM PM Sheet 2702
PD-7011 Molybdenum Alloy TZM PM Plate 2703
PD-7004 Molybdenum Alloy TZM AC Plate 3403
PD-7005 Molybdenum Alloy TZM AC Sheet 3402
PD-7021 Molybdenum Alloy TZM AFBT AC Forging Billet
PD-7025 Molybdenum Alloy TZM ABT AC Bar
PD-7031 Molybdenum Alloy P/M TZM PM Billet
PD-7043 Molybdenum Alloy ODS Mo-La PM Sheet 2602
PD-7044 Molybdenum Alloy ODS Mo-La PM Plate 2603
PD-7020 Molybdenum Alloy AFB-30W AC Forging Billet
PD-7022 Molybdenum Alloy AFB AC Forging Billet
PD-7024 Molybdenum Alloy AB-30W AC Bar
PD-7008 Molybdenum Alloy PBT PM Bar
Molybdenum Plate Processing
The majority of normal processing can be performed on Molybdenum Plate
MD Exports LLP Offers Following process for Molybdenum Plate
Molybdenum Plate Packing & Shipping
Each order is packaged according to the customer’ s standards including preparation for export such as wooden case, pallet or according to customer’s requirement All shipping documentation is provided for Molybdenum Plate delivery from mill to customer.
Every assignment begins with a visit of our experienced sales representative who assesses the volume / weight of the belongings and brief the client about the nature of packing required as well as various documentation formalities when moving from India.
Supply Area :
We Supply Our Molybdenum Plate to various countries like Saudi arabia, Kuwait, Qatar, Oman, Yemen, UAE, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Vietnam, South Africa,South America,Brazil, India, Australia, Egypt.
Molybdenum Plate Inventory
Molybdenum Plate Application Industries
MD Exports LLP offers a broad range of Molybdenum Plate through a worldwide network of stock-keeping branches.these Molybdenum Plate is use in various industries like:
- Fertilizers Industry
- Aerospace Industry
- Nuclear Power Plant Industry
- Chemical Industry
- Oil & Gas Industry
- Refineries Industry
- Petrochemical Industry
- Paper Industry
MD Exports LLP inc is largest suppliers of Molybdenum Plate. we are supplying Molybdenum Plate in Saudi arabia, Kuwait, Qatar, Oman, Yemen, UAE, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Vietnam, South Africa,South America,Brazil, India, Australia, Egypt.we assured our client that we are standing behind our product which we have supplied as well as we issued a quality certificate along with our product which we manufacture supplies and exports
